Q18. for the circuit shown in Fig Q1, determine EACH of the following:

(a) The current supplied by each battery;

(b) The voltage across the 8Ω load resistor;

(c) The power dissipated in the 8Ω resistor.

Q10. A relay coil has resistance of 200Ω and the current required to operate the relay is 150 mA. When the relay is connected to a 50 V d.c. supply the time between switch on and the operation of the relay is 40 ms.

(a) Calculate EACH of the following:

(i) The steady state relay current;

(ii) The time constant for the coil;

(iii) The inductance of the coil.

(b) To increase the operating time delay for the relay a 50 resistor is connected in series with the coil. Calculate the new time delay for the relay.

Q1. A small silicon transistor with the characteristics given in Worksheet Q3 has a maximum safe power dissipation of 18 mW and it is to be operated on a 12 volt d.c. supply.

(a) Plot the maximum power dissipation curve on the characteristics.

(b) Determine the minimum value of collector load resistance for the transistor if this dissipation is not to be exceeded.

(c) If the transistor is used in a common emitter configuration and is biased at a base current of 60 mA and an alternating signal of  40 mA is applied to the base,

determine EACH of the following:

(i) The r.m.s. voltage variation between collector and emitter;

(ii) The r.m.s. value of the variation in collector current.

Q11. A series circuit comprising a 50Ω resistor, a capacitor and a coil having resistance and inductance is connected across a 50 V variable frequency supply.

When the frequency is 400 Hz the current reaches its maximum value of 0.6 A and the voltage across the capacitor is 200 V. Calculate EACH of the following:

(a) The value of the capacitance;

(b) The resistance and inductance of the coil;

(c) The power taken;

(d) The circuit power factor.

Q13. A balanced three phase delta connected load comprises a coil of resistance 50Ω and inductance 0.1 H in each phase. It is connected to a 440 V 50 Hz supply. Calculate EACH of the following:

(a) The line current for the load;

(b) The power factor of the load;

(c) The power dissipated by the load;

(d) The component values in each leg of a star connected load which would draw the same line current at a leading power factor numerically equal to that found in Q5(b).

Q2. The load on a vessel’s distribution system comprises:

- motors totalling 1200 kW at a p.f. of 0.7 lag

- lighting totalling 500 kW at unity p.f.

- an over excited synchronous motor taking 200 kW at p.f. 0.5 lead

This total load is shared by two identical alternators, one of which provides 1000 kVA at a p.f. of 0.85 lag.

Calculate EACH of the following:

(a) the kW supplied by the second alternator; (3)

(b) the kVA supplied by the second alternator; (5)

(c) the power factor of the second alternator; (3)

(d) the power factor of the synchronous motor if the overall p.f of the system is to be raised to unity. (5)
